Engineering Design Kits

Custom Capacitor KitsCustom and Engineering Kit Brochure

Passive Plus offers over 40 Design Kits for engineers who are building and testing prototypes. Each kit contains 10 pieces per value. Please note that certain case sizes are also offered in Non-Magnetic Terminations.

Check the “Inquire” box for all capacitor kits you want to order and complete the form at the bottom to send your request.

Jump to series section

Traditional High-Q Low ESR

0505C - (.055 x .055)
0505P - (.055 x .055)
1111C - (.110 x .110)
1111P - (.110 x .110)

Traditional High-Q Low ESR – NON-MAGNETIC

0505C - (.055 x .055)
0505P - (.055 x .055)
1111C - (.110 x .110)
1111P - (.110 x .110)

Ultra-Low ESR

0201N - (.020 X .010)
0402N - (.040 x .020)
0603N - (.060 x .030)
0805N - (.080 x .050)
1111N - (.110 x .110)

Series: 0505C - (.055 x .055) Traditional High-Q Low ESR (NP0 TC)

DKD0505C01

Range (pF)
.1 - 2.0

Capacitance (pF)
0.1, 0.2, 0.3, 0.4, 0.5, 0.6, 0.7, 0.8, 0.9, 1.0, 1.1, 1.2, 1.5, 1.6, 1.8, 2.0

Values
16

DKD0505C02

Range (pF)
1.0 - 10

Capacitance (pF)
1.0, 1.2, 1.5, 1.8, 2.0, 2.2, 2.4, 2.7, 3.0, 3.3, 3.9, 4.7, 5.6, 6.8, 8.2, 10

Values
16

DKD0505C03

Range (pF)
10 - 100

Capacitance (pF)
10, 12, 15 ,18 ,20, 22, 24, 27, 30, 33 ,39, 47 ,56, 68, 82, 100

Values
16

DKD0505C04

Range (pF)
100 - 1000

Capacitance (pF)
100, 120, 150, 180, 200, 220, 240, 270, 300, 330, 390, 470, 560, 680, 820, 1000

Values
16

Series: 0505C - NON-MAGNETIC - (.055 x .055) Traditional High-Q Low ESR (NP0 TC)

DKD0505C05

Range (pF)
.1 - 2.0

Capacitance (pF)
0.1, 0.2, 0.3, 0.4, 0.5, 0.6, 0.7, 0.8, 0.9, 1.0, 1.1, 1.2, 1.5, 1.6, 1.8, 2.0

Values
16

DKD0505C06

Range (pF)
1.0 - 10

Capacitance (pF)
1.0, 1.2, 1.5, 1.8, 2.0, 2.2, 2.4, 2.7, 3.0, 3.3, 3.9, 4.7, 5.6, 6.8, 8.2, 10

Values
16

DKD0505C07

Range (pF)
10 - 100

Capacitance (pF)
10, 12, 15, 18, 20, 22, 24, 27, 30, 33, 39, 47, 56, 68, 82, 100

Values
16

DKD0505C08

Range (pF)
100 - 1000

Capacitance (pF)
100, 120, 150, 180, 200, 220, 240, 270, 300, 330, 390, 470, 560, 680, 820, 1000

Values
16

Series: 0505P - (.055 x .055) Traditional High-Q Low ESR (P90 TC)

DKD0505P01

Range (pF)
.1 - 2.0

Capacitance (pF)
0.1, 0.2, 0.3, 0.4, 0.5, 0.6, 0.7, 0.8, 0.9, 1.0, 1.1, 1.2, 1.5, 1.6, 1.8, 2.0

Values
16

DKD0505P02

Range (pF)
1.0 - 10

Capacitance (pF)
1.0, 1.2, 1.5, 1.8, 2.0, 2.2, 2.4, 2.7, 3.0, 3.3, 3.9, 4.7, 5.6, 6.8, 8.2, 10

Values
16

DKD0505P03

Range (pF)
10 - 100

Capacitance (pF)
10, 12, 15, 18, 20, 22, 24, 27, 30, 33, 39, 47, 56, 68, 82, 100

Values
16

Series: 0505P - NON-MAGNETIC - (.055 x .055) Traditional High-Q Low ESR (P90 TC)

DKD0505P05

Range (pF)
.1 - 2.0

Capacitance (pF)
0.1, 0.2, 0.3, 0.4, 0.5, 0.6, 0.7, 0.8, 0.9, 1.0, 1.1, 1.2, 1.5, 1.6, 1.8, 2.0

Values
16

DKD0505P06

Range (pF)
1 - 10

Capacitance (pF)
1.0, 1.2, 1.5, 1.8, 2.0, 2.2, 2.4, 2.7, 3.0, 3.3, 3.9, 4.7, 5.6, 6.8, 8.2, 10

Values
16

DKD0505P07

Range (pF)
10 - 100

Capacitance (pF)
10, 12, 15, 18, 20, 22, 24, 27, 30, 33, 39, 47, 56, 68, 82, 100

Values
16

Series: 1111C - (.110 x .110) Traditional High-Q Low ESR (NP0 TC)

DKD1111C01

Range (pF)
1.0 - 10

Capacitance (pF)
1.0, 1.2, 1.5, 1.8, 2.0, 2.2, 2.4, 2.7, 3.0, 3.3, 3.9, 4.7, 5.6, 6.8, 8.2, 10

Values
16

DKD1111C02

Range (pF)
10 - 100

Capacitance (pF)
10, 12, 15 ,18 ,20, 22, 24, 27, 30, 33 ,39, 47 ,56, 68, 82, 100

Values
16

DKD1111C03

Range (pF)
100 - 1000

Capacitance (pF)
100, 120, 150, 180, 200, 220, 240, 270, 300, 330, 390, 470, 560, 680, 820, 1000

Values
16

DKD1111C04

Range (pF)
1000 - 10000

Capacitance (pF)
1000, 1100, 1200, 1500, 1800, 2000, 2200, 2700, 3000, 3300, 3900, 4700, 5100, 5600, 10000

Values
14

Series: 1111C - NON-MAGNETIC - (.110 x .110) Traditional High-Q Low ESR (NP0 TC)

DKD1111C05

Range (pF)
1.0 - 10

Capacitance (pF)
1.0, 1.2, 1.5, 1.8, 2.0, 2.2, 2.4, 2.7, 3.0, 3.3, 3.9, 4.7, 5.6, 6.8, 8.2, 10

Values
16

DKD1111C06

Range (pF)
10 - 100

Capacitance (pF)
10, 12, 15 ,18 ,20, 22, 24, 27, 30, 33 ,39, 47 ,56, 68, 82, 100

Values
16

DKD1111C07

Range (pF)
100 - 1000

Capacitance (pF)
100, 120, 150, 180, 200, 220, 240, 270, 300, 330, 390, 470, 560, 680, 820, 1000

Values
16

DKD1111C08

Range (pF)
1000 - 10000

Capacitance (pF)
1000, 1100, 1200, 1500, 1800, 2000, 2200, 2700, 3000, 3300, 3900, 4700, 5100, 5600, 10000

Values
14

Series: 1111P - (.110 x .110) Traditional High-Q Low ESR (P90 TC)

DKD1111P01

Range (pF)
1.0 - 10

Capacitance (pF)
1.0, 1.2, 1.5, 1.8, 2.0, 2.2, 2.4, 2.7, 3.0, 3.3, 3.9, 4.7, 5.6, 6.8, 8.2, 10

Values
16

DKD1111P02

Range (pF)
10 - 100

Capacitance (pF)
10, 12, 15 ,18 ,20, 22, 24, 27, 30, 33, 39, 47 ,56, 68, 82, 100

Values
16

DKD1111P03

Range (pF)
100 - 1000

Capacitance (pF)
100, 120, 150, 180, 200, 220, 240, 270, 300, 330, 390, 470, 560, 680, 820, 1000

Values
16

DKD1111P04

Range (pF)
1000 - 10000

Capacitance (pF)
1000, 1100, 1200, 1500, 1800, 2000, 2200, 2700, 3000, 3300, 3900, 4700, 5100, 5600, 10000

Values
14

Series: 1111P - NON-MAGNETIC - (.110 x .110) Traditional High-Q Low ESR (P90 TC)

DKD1111P05

Range (pF)
1.0 - 10

Capacitance (pF)
1.0, 1.2, 1.5, 1.8, 2.0, 2.2, 2.4, 2.7, 3.0, 3.3, 3.9, 4.7, 5.6, 6.8, 8.2, 10

Values
16

DKD1111P06

Range (pF)
10 - 100

Capacitance (pF)
10, 12, 15 ,18 ,20, 22, 24, 27, 30, 33, 39, 47 ,56, 68, 82, 100

Values
16

DKD1111P07

Range (pF)
100 - 1000

Capacitance (pF)
100, 120, 150, 180, 200, 220, 240, 270, 300, 330, 390, 470, 560, 680, 820, 1000

Values
16

DKD1111P08

Range (pF)
1000 - 10000

Capacitance (pF)
1000, 1100, 1200, 1500, 1800, 2000, 2200, 2700, 3000, 3300, 3900, 4700, 5100, 5600, 10000

Values
14

Series: 0201N - (.020 X .010) Ultra-Low ESR

DKD0201N01

Range (pF)
.1 - 2.0

Capacitance (pF)
0.1, 0.2, 0.3, 0.5, 0.7, 0.8, 0.9, 1.0, 1.3, 1.5, 1.7, 1.9, 2.0

Values
13

DKD0201N02

Range (pF)
1.0 - 10

Capacitance (pF)
1.0, 1.3, 1.5, 1.7, 1.9, 2.0, 2.2, 2.7, 3.0, 3.9, 4.7, 5.6, 6.8, 7.5, 8.2, 10

Values
16

DKD0201N03

Range (pF)
10 - 100

Capacitance (pF)
10, 13, 15, 18, 20, 22, 27, 30, 39, 47, 56, 68, 75, 82, 91, 100

Values
16

Series: 0402N - (.040 x .020) Ultra-Low ESR

DKD0402N01

Range (pF)
.1 - 2.0

Capacitance (pF)
0.1, 0.2, 0.3, 0.4, 0.5, 0.6, 0.7, 0.8, 0.9, 1.0, 1.2, 1.5, 1.6, 1.8, 2.0

Values
15

DKD0402N02

Range (pF)
1.0 - 10

Capacitance (pF)
1.0, 1.2, 1.5, 1.8, 2.0, 2.2, 2.4, 2.7, 3.0, 3.3, 3.9, 4.7, 5.6, 6.8, 8.2, 10

Values
16

DKD0402N03

Range (pF)
10 - 33

Capacitance (pF)
10, 12, 13, 15, 16, 18, 20, 22, 24, 27, 30, 33

Values
12

Series: 0603N - (.060 x .030) Ultra-Low ESR

DKD0603N01

Range (pF)
.1 - 2.0

Capacitance (pF)
0.1, 0.2, 0.3, 0.4, 0.5, 0.6, 0.7, 0.8, 0.9, 1.0, 1.1, 1.2, 1.5, 1.6, 1.8, 2.0

Values
16

DKD0603N02

Range (pF)
1.0 - 10

Capacitance (pF)
1.0, 1.2, 1.5, 1.8, 2.0, 2.2, 2.4, 2.7, 3.0, 3.3, 3.9, 4.7, 5.6, 6.8, 8.2, 10

Values
16

DKD0603N03

Range (pF)
10 - 100

Capacitance (pF)
10, 12, 15, 18, 20, 22, 24, 27, 30, 33, 39, 47, 56, 68, 82, 100

Values
16

Series: 0805N - (.080 x .050) Ultra-Low ESR

DKD0805N01

Range (pF)
.1 - 2.0

Capacitance (pF)
0.1, 0.2, 0.3, 0.4, 0.5, 0.6, 0.7, 0.8, 0.9, 1.0, 1.2, 1.5, 1.6, 1.8, 2.0

Values
15

DKD0805N02

Range (pF)
1.0 - 10

Capacitance (pF)
1.0, 1.2, 1.5, 1.8, 2.0, 2.2, 2.4, 2.7, 3.0, 3.3, 3.9, 4.7, 5.6, 6.8, 8.2, 10

Values
16

DKD0805N03

Range (pF)
10 - 100

Capacitance (pF)
10, 12, 15, 18, 20, 22, 24, 27, 30, 33, 39, 47, 56, 68, 82, 100

Values
16

DKD0805N04

Range (pF)
10 - 220

Capacitance (pF)
10, 15, 18, 20, 27, 30, 39, 47, 56, 68, 82, 100, 120, 150, 180, 220

Values
16

Series: 1111N - (.110 x .110) Ultra-Low ESR

DKD1111N01

Range (pF)
1.0 - 10

Capacitance (pF)
1.0, 1.2, 1.5, 1.8, 2.0, 2.2, 2.4, 2.7, 3.0, 3.3, 3.9, 4.7, 5.6, 6.8, 8.2, 10

Values
16

DKD1111N02

Range (pF)
10 - 100

Capacitance (pF)
10, 12, 15, 18, 20, 22, 24, 27, 30, 33, 39, 47, 56, 68, 82, 100

Values
16

DKD1111N03

Range (pF)
100 - 1000

Capacitance (pF)
100, 120, 150, 180, 200, 220, 240, 270, 300, 330, 390, 470, 560, 680, 820, 1000

Values
16
